Product Overview: Current Measurement
Component
Module
Kit
System
CDK4000 CMK2000 CDS4006 CDS4010 CDS4015 CDS4025 CDS4050 CDS4100 CDS4125 CDS4150 CMS2005 CMS2015 CMS2025 CMS2050
CDK4000

CDK4000 Demoboard for CDS4000 Current Sensors

Advantages

  • Very simple handling by usual connection terminals
  • Space allocated for components needed for overcurrent detection
  • Easy switching between current and voltage output signal

CDK4000 The CDK4000 demoboard offers the opportunity to learn the features and benefits of the CDS4000 current sensors in a quick and simple manner. On the reverse side all signal pins ...

CDS4006

CDS4006 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Very small size
  • Highly dynamic response
  • Automatically mountable on PCB
  • External reference possible
  • Low primary inductance
  • Negligible hysteresis

CDS4006 The CDS4000 current sensor family is designed for highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent dynamic ...

Product Overview CDS4006
Article Description Package Delivery Type
CDS4006ABC-KA THT Tray
CDK4006ABC-KA Demoboard Pocketbox
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 1 s in a 60 s interval; RM = 300 Ω.
2) εΣ = εG & εoff & εlin with VCC = 5 V and Tamb = 25 °C.
3) Operating condition.
VCC Supply voltage 4.75 5 5.25 V
IPN Primary nominal current (RMS) - - 6 A
IPR Primary measuring range 1) -18 - +18 A
εΣ  Overall accuracy 2) - 0.8 1.3 % of IPN
fco Upper cut-off frequency (-1 dB) 200 400 - kHz
Tamb Ambient temperature 3) -40 - +105 °C
TB Busbar temperature 3) -40 - +105 °C
CDS4010

CDS4010 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Very small size
  • Highly dynamic response
  • Automatically mountable on PCB
  • External reference possible
  • Low primary inductance
  • Negligible hysteresis

CDS4010 The CDS4000 current sensor family is designed for highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent dynamic ...

Product Overview CDS4010
Article Description Package Delivery Type
CDS4010ABC-KA THT Tray
CDK4010ABC-KA Demoboard Pocketbox
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 1 s in a 60 s interval; RM = 300 Ω.
2) εΣ = εG & εoff & εlin with VCC = 5 V and Tamb = 25 °C.
3) Operating condition.
VCC Supply voltage 4.75 5 5.25 V
IPN Primary nominal current (RMS) - - 10 A
IPR Primary measuring range 1) -30 - +30 A
εΣ  Overall accuracy 2) - 0.8 1.3 % of IPN
fco Upper cut-off frequency (-1 dB) 200 400 - kHz
Tamb Ambient temperature 3) -40 - +105 °C
TB Busbar temperature 3) -40 - +105 °C
CDS4015

CDS4015 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Very small size
  • Highly dynamic response
  • Automatically mountable on PCB
  • External reference possible
  • Low primary inductance
  • Negligible hysteresis

CDS4015 The CDS4000 current sensor family is designed for highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent dynamic ...

Product Overview CDS4015
Article Description Package Delivery Type
CDS4015ABC-KA THT Tray
CDK4015ABC-KA Demoboard Pocketbox
Technical Data
Symbol Parameter Min. Typ. Max. Einheit
1) For 1 s in a 60 s interval; RM = 300 Ω.
2) εΣ = εG & εoff & εlin with VCC = 5 V and Tamb = 25 °C.
3) Operating condition.
VCC Supply voltage 4.75 5 5.25 V
IPN Primary nominal current (RMS) - - 15 A
IPR Primary measuring range 1) -45 - +45 A
εΣ  Overall accuracy 2) - 0.8 1.3 % of IPN
fco Upper cut-off frequency (-1 dB) 200 400 - kHz
Tamb Ambient temperature 3) -40 - +105 °C
TB Busbar temperature 3) -40 - +105 °C
CDS4025

CDS4025 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Very small size
  • Highly dynamic response
  • Automatically mountable on PCB
  • External reference possible
  • Low primary inductance
  • Negligible hysteresis

CDS4025 The CDS4000 current sensor family is designed for highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent dynamic ...

Product Overview CDS4025
Article Description/th> Package Delivery Type
CDS4025ABC-KA THT Tray
CDK4025ABC-KA Demoboard Pocketbox
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 1 s in a 60 s interval; RM = 300 Ω.
2) εΣ = εG & εoff & εlin with VCC = 5 V and Tamb = 25 °C.
3) Operating condition.
VCC Supply voltage 4.75 5 5.25 V
IPN Primary nominal current (RMS) - - 25 A
IPR Primary measuring range 1) -75 - +75 A
εΣ  Overall accuracy 2) - 0.8 1.3 % of IPN
fco Upper cut-off frequency (-1 dB) 200 400 - kHz
Tamb Ambient temperature 3) -40 - +105 °C
TB Busbar temperature 3) -40 - +105 °C
CDS4050

CDS4050 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Very small size
  • Highly dynamic response
  • Automatically mountable on PCB
  • External reference possible
  • Low primary inductance
  • Negligible hysteresis

CDS4050 The CDS4000 current sensor family is designed for highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent dynamic ...

Product Overview CDS4050
Article Description Package Delivery Type
CDS4050ABC-KA THT (small) Tray
CDK4050ABC-KA Demoboard Pocketbox
CDS4050ACC-KA THT (medium) Tray
CDK4050ACC-KA Demoboard Pocketbox
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 1 s in a 60 s interval; RM = 300 Ω.
2) εΣ = εG & εoff & εlin with VCC = 5 V and Tamb = 25 °C.
3) Operating condition.
VCC Supply voltage 4.75 5 5.25 V
IPN Primary nominal current (RMS) - - 50 A
IPR Primary measuring range 1) -150 - +150 A
εΣ  Overall accuracy 2) - 0.8 1.3 % of IPN
fco Upper cut-off frequency (-1 dB) 200 400 - kHz
Tamb Ambient temperature 3) -40 - +105 °C
TB Busbar temperature 3) -40 - +105 °C
CDS4100

CDS4100 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Very small size
  • Highly dynamic response
  • Automatically mountable on PCB
  • External reference possible
  • Low primary inductance
  • Negligible hysteresis

CDS4100 The CDS4000 current sensor family is designed for highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent dynamic ...

Product Overview CDS4100
Article Description Package Delivery Type
CDS4100ACC-KA THT Tray
CDK4100ACC-KA Demoboard Pocketbox
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 1 s in a 60 s interval; RM = 300 Ω.
2) εΣ = εG & εoff & εlin with VCC = 5 V and Tamb = 25 °C.
3) Operating condition.
VCC Supply voltage 4.75 5 5.25 V
IPN Primary nominal current (RMS) - - 100 A
IPR Primary measuring range 1) -300 - +300 A
εΣ  Overall accuracy 2) - 0.8 1.3 % of IPN
fco Upper cut-off frequency (-1 dB) 200 400 - kHz
Tamb Ambient temperature 3) -40 - +105 °C
TB Busbar temperature 3) -40 - +105 °C
CDS4125

CDS4125 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Very small size
  • Highly dynamic response
  • Automatically mountable on PCB
  • External reference possible
  • Low primary inductance
  • Negligible hysteresis

CDS4125 The CDS4000 current sensor family is designed for highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent dynamic ...

Product Overview CDS4125
Article Description Package Delivery Type
CDS4125ACC-KA THT Tray
CDK4125ACC-KA Demoboard Pocketbox
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 1 s in a 60 s interval; RM = 300 Ω.
2) εΣ = εG & εoff & εlin with VCC = 5 V and Tamb = 25 °C.
3) Operating condition.
VCC Supply voltage 4.75 5 5.25 V
IPN Primary nominal current (RMS) - - 125 A
IPR Primary measuring range 1) -375 - +375 A
εΣ  Overall accuracy 2) - 0.8 1.3 % of IPN
fco Upper cut-off frequency (-1 dB) 200 400 - kHz
Tamb Ambient temperature 3) -40 - +105 °C
TB Busbar temperature 3) -40 - +105 °C
CDS4150

CDS4150 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Very small size
  • Highly dynamic response
  • Automatically mountable on PCB
  • External reference possible
  • Low primary inductance
  • Negligible hysteresis

CDS4150 The CDS4000 current sensor family is designed for highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent dynamic ...

Product Overview CDS4150
Article Description Package Delivery Type
CDS4150ACC-KA THT Tray
CDK4150ACC-KA Demoboard Pocketbox
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 1 s in a 60 s interval; RM = 300 Ω.
2) εΣ = εG & εoff & εlin with VCC = 5 V and Tamb = 25 °C.
3) Operating condition.
VCC Supply voltage 4.75 5 5.25 V
IPN Primary nominal current (RMS) - - 150 A
IPR Primary measuring range 1) -450 - +450 A
εΣ  Overall accuracy 2) - 0.8 1.3 % of IPN
fco Upper cut-off frequency (-1 dB) 200 400 - kHz
Tamb Ambient temperature 3) -40 - +105 °C
TB Busbar temperature 3) -40 - +105 °C
CMK2000

CMK2000 Demoboard for CMS2000 Family

Advantages

  • Very simple handling by usual connection terminals
  • Easy switching between active and passive filter on output signal*/

CMK2000 The CMK2000 demoboard offers the opportunity to learn the features and benefits of the CMS2000 current sensors in a quick and simple manner. The primary current to be measured can ...

CMS2005

CMS2005 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Small and compact size
  • Highly dynamic response
  • Integrated burden resistor
  • Low primary inductance
  • Negligble hysteresis

CMS2005 The CMS2000 current sensor family is designed for a highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent ...

porduct overview
Description Package Delivery type
CMS2005-SP3 THT Tray
CMS2005-SP10 THT Tray
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 3 s in a 60 s interval and VCC = 15V
2) Operating condition
VCC Positive supply voltage +11,4 +15,0 +15,7 V
VEE Negative supply voltage -11,4 -15,0 -15,7 V
IPN Primary nominal current (RMS) - - 5 A
IPR Primary measuring range 1) -15 - +15 A
fco Upper cut-off frequency (-3 dB) - 100 - kHz
Tamb Ambient temperature 2) -25 - +85 °C
CMS2015

CMS2015 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Small and compact size
  • Highly dynamic response
  • Integrated burden resistor
  • Low primary inductance
  • Negligble hysteresis

CMS2015 The CMS2000 current sensor family is designed for a highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent ...

porduct overview
Description Package Delivery type
CMS2015-SP3 THT Tray
CMS2015-SP10 THT Tray
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 3 s in a 60 s interval and VCC = 15V
2) Operating condition
VCC Positive supply voltage +11,4 +15,0 +15,7 V
VEE Negative supply voltage -11,4 -15,0 -15,7 V
IPN Primary nominal current (RMS) - - 15 A
IPR Primary measuring range 1) -45 - +45 A
fco Upper cut-off frequency (-3 dB) - 100 - kHz
Tamb Ambient temperature 2) -25 - +85 °C
CMS2025

CMS2025 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Small and compact size
  • Highly dynamic response
  • Integrated burden resistor
  • Low primary inductance
  • Negligble hysteresis

CMS2025 The CMS2000 current sensor family is designed for a highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent ...

porduct overview
Description Package Delivery type
CMS2025-SP3 THT Tray
CMS2025-SP10 THT Tray
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 3 s in a 60 s interval and VCC = 15V
2) Operating condition
VCC Positive supply voltage +11,4 +15,0 +15,7 V
VEE Negative supply voltage -11,4 -15,0 -15,7 V
IPN Primary nominal current (RMS) - - 25 A
IPR Primary measuring range 1) -75 - +75 A
fco Upper cut-off frequency (-3 dB) - 100 - kHz
Tamb Ambient temperature 2) -25 - +85 °C
CMS2050

CMS2050 MagnetoResistive Current Sensor

Advantages

  • Excellent accuracy
  • Low temperature drift
  • Small and compact size
  • Highly dynamic response
  • Integrated burden resistor
  • Low primary inductance
  • Negligble hysteresis

CMS2050 The CMS2000 current sensor family is designed for a highly dynamic electronic measurement of DC, AC, pulsed and mixed currents with integrated galvanic isolation. The MagnetoResistive technology enables an excellent ...

porduct overview
Description Package Delivery type
CMS2050-SP3 THT Tray
CMS2050-SP7 THT Tray
CMS2025-SP10 THT Tray
Technical Data
Symbol Parameter Min. Typ. Max. Unit
1) For 3 s in a 60 s interval and VCC = 15V
2) For 20 ms in a 60 s interval and VCC = 15V
3) Operating condition
VCC Positive supply voltage +11,4 +15,0 +15,7 V
VEE Negative supply voltage -11,4 -15,0 -15,7 V
IPN Primary nominal current (RMS) - - 50 A
IPR Primary measuring range 1) -150 - +150 A
IPR,SP3 Primary measuring range 2) -220 - +220 A
fco Upper cut-off frequency (-3 dB) - 100 - kHz
Tamb Ambient temperature 3) -25 - +85 °C
